REACT - Inhaler BLE Monitor

The BLE Inhaler Monitor is a small PCB unit with a Bluetooth microcontroller and a pressure sensor, powered by a battery. Enclosed in a 3D printed case, the unit is mounted on the top of a regular Inhaler device.

It monitors the time and amount of intakes through the pressures on the unit from a patient and the data is sent via Bluetooth to a nearby connected smartphone. An external team of smartphone app developers created the app for this application. From there it is sent to a cloud database for further analysis.

Click on the images for a larger view.



PCB with BLE microchip and pressure sensor    Unit is mounted on top of inhaler
